Contemporary

SIGMA 45mm F2.8
DG DN | Contemporary

€549
Choose a mount to see availability

• Robuuste bouwkwaliteit
• Prachtige bokeh een scherpte
• Afgerond diafragma
• Stof- en spatwaterdichte structuur
• Snelle AF
• Ontworpen om flare en ghosting te minimaliseren
• Compatibel met lensaberratiecorrectie

Specifications
Eigenschappen
Construction
Technology
Productlijn Contemporary
Youtube Videos
Instagram Widget
Klevu Image /p/r/product_img01_9_1.png
Lensconstructie 8 Elements in 7 Groups
Lens Type Standard
Sensor Size Full Frame
Beeldhoek 51.3º
Aantal diafragmalamellen 7 (Rounded Diaphragm)
Minimaal diafragma F22
Minimale scherpstelafstand 24 cm
Maximale vergroting 1:4
Afmetingen (diameter x lengte)

Sony E-mount
L-Mount

⌀ 64.0 mm x 48.2 mm
⌀ 64.0 mm x 46.2 mm

Filtermaat 55mm
Edition number C019
Accessoires Lens Hood (LH577-01) supplied
EAN-code

L-Mount
Sony E-mount

085126360696
085126360658

I series | A new photographic experience, “Premium Compact Primes” for mirrorless users

The Sigma I series features full-frame-compatible lenses that offer mirrorless users a new and better alternative, both in the experience of shooting with the lens and in the impressive results it is able to achieve.
One of the key advantages of mirrorless cameras is their smaller form-factor, and this new 35mm optic is designed to be perfectly matched to these more compact systems without sacrificing performance. This combination of superb optical quality with exceptional portability, not previously possible with DSLR systems, will bring new opportunities to this and future generations of photographers.
Simultaneously, Sigma is aware that, in this day and age when we have such huge diversity when it comes to what we use to photograph, as represented by smartphones, people look for something more than a mere act of “taking pictures” when they choose to own a camera and lenses.
Sigma’s excellence in development and processing technologies has been built up since its founding in 1961, and has become further sophisticated with the introduction of the Sigma Global Vision in 2012. With this as a base, Sigma has given careful thought how photographers use and enjoy their lenses, including optical design, advanced functionality, build quality and the experience of picking up and using the lens, and with all of this carefully considered, the I series was born.

Beautiful bokeh and rendering that can be enjoyed in every scene

With the Sigma 45mm F2.8 DG DN | Contemporary, bokeh expressions are especially featured. Spherical aberration has been controlled to ensure not only the large bokeh in the front and rear of the subject but also the rear bokeh near the area in focus create a gradient to a soft blur. This lens softens the periphery of blurred images suppressing the double-line bokeh etc. and enhances the three-dimensional impression of the subject with the smooth expressions in the foreground and the background. In addition, its minimum focusing distance of 24cm makes it possible to enjoy shooting snapshots and tabletop photos taking advantage of the angle of view. The design gives consideration to vignetting to achieve beautiful round bokeh and subdue swirly bokeh in the whole bokeh effects.
While this lens produces smooth bokeh effects of which one could say as “classical expression” when the aperture is wide open, it also realizes modern sharp rendering when it is stopped down. It is reassuring to hold this lens as the regular lens for everyday use.

High build quality and outstanding operability

Because this lens is intended for everyday use, particular attention has been given to build quality and operability. The lens barrel incorporating metal material as the main part achieves improved durability. Furthermore, thanks to the aperture ring with the right click feeling, comfortable operability during various shooting styles is ensured. The design gives consideration to MF operations, and a ring of appropriate torque provides good operability.

Metal bayonet hood

The lens hood features aluminium, using the same material as the lens body which has realized high quality and high rigidity.
Furthermore, cared for the click feeling at the time of when removing and attaching, the knurling process featured on the surface provides a superior usability.

High-speed and highly accurate AF enabled by the stepping motor

The lens is capable of smooth, quiet and high-speed AF made possible by a stepping motor, as well as supports Face/Eye Detection AF and video AF.

LENS CONSTRUCTION

GEOMETRICAL MTF Chart

DIFFRACTION MTF CHART

Focus Mode Switch

Using this swich, it is possible to switch the focus mode between AF and MF.

Linear focus / Non-linear focus (for L-Mount only)

A focus movement method of interchangeable lenses for mirrorless cameras (DN lens) in relation to the rotational angle of the focus ring during manual focusing.
With "non-linear focus," the amount of focal point movement varies depending on the focus ring rotational speed.
With linear focus, if the focus ring rotational angle is the same, the amount of focal point movement remains the same regardless of the focus ring rotational speed.

High-precision, rugged brass bayonet mount

The brass mount combines high precision with rugged construction. Its treated surfaces and enhanced strength contribute to the exceptional durability of the lens.

Rounded diaphragm

Exclusive low-dispersion glass

Exclusive low-dispersion glass



The degree to which light is refracted by glass depends on the light's wavelength. This fact causes different colors of light to focus at slightly different points. The result is chromatic aberration, the color fringing that is particularly noticeable in telephoto lenses. Most chromatic aberration can be removed by combining a high-refractivity convex lens element with a low-refractivity concave element. Yet residual chromatic aberration known as "secondary spectrum" may still remain. To minimize this secondary spectrum, which can be a serious issue with conventional lenses, SIGMA lenses feature up to three types of exclusive low-dispersion glass offering superior performance: ELD (Extraordinary Low Dispersion), SLD (Special Low Dispersion) and FLD ("F" Low Dispersion). In particular, FLD glass offers ultra-low dispersion in combination with high transmittance and the anomalous dispersion characteristics of fluorite. Meticulous deployment of these types of exclusive low-dispersion glass and optimization of power distribution gives SIGMA lenses superlative image rendition undiminished by residual chromatic aberration.

Lens construction: 8 elements in 7 groups (2 aspherical lenses)





Compatible with high-speed autofocus

Support for DMF, AF + MF



Lens Hood

Compatible with SIGMA USB DOCK UD-11 (sold separately; L-Mount only)

Designed to minimize flare and ghosting

7-blade rounded diaphragm

High-precision, durable brass bayonet mount
