fp L - Mirrorless Camera
• 61 megapixels, 35mm fullframe sensor
• Hybride AF-systeem, contrast- en fasedetectie-AF
• Stof- en spatwaterdichte behuizing
• Naadloos omschakelen tussen foto en video
• Directors Viewfinder
| Product subtitle | Small in size with the highest resolution | ||||||
|---|---|---|---|---|---|---|---|
| Specificaties | * All figures calculated by L-Mount. Note: The L-Mount Trademark is a registered Trademark of Leica Camera AG. About Product Name: Product name includes "DG" when the lens is designed to deliver the ultimate in performance on cameras with full-frame sensors, and "DN" when the lens design is optimized for mirrorless cameras with the short flange focal length |
||||||
| Youtube Videos | |||||||
| Youtube Channel Link | https://www.youtube.com/channel/UCj0Y0mbE0gdB3Ou4zxeWeoQ | ||||||
| Instagram Widget | |||||||
| Format Type | Interchangeable-lens Mirrorless Type Digital Camera | ||||||
| Storage Media | SD, SDHC, SDXC memory card (UHS-Ⅱ supported) , Portable SSD (USB 3.0 connection, USB bus power supported) | ||||||
| Sensor type | 35 mm full-frame (36.0 mm x 24.0 mm) Back-illuminated Bayer CMOS sensor | ||||||
| Camera effective pixels / Total pixels | Approx. 61 MP (Net) / Approx. 62.4 MP (Gross) | ||||||
| Sensor | 36.0 mm x 24.0 mm | ||||||
| Beeldverhouding | 3:2 | ||||||
| Color, filter system | RGB Primary color filter | ||||||
| Still Image File Format | Lossless compression RAW(DNG) data 12 bit,14 bit / JPEG(Exif2.3), RAW(DNG)+JPEG:recording is possible | ||||||
| Image aspect ratio | [21:9] / [16:9] / [3:2] / [A Size (√2:1) ] / [4:3] / [7:6] / [1:1] | ||||||
| File size - RAW | 9.5K : 9,520 x 6,328 / 6.2K : 6,240 x 4,144 / 4.8K : 4,768 x 3,168 / UHD : 3,840 x 2,552 / FHD : 1,920 x 1,280 | ||||||
| JPEG file size | [21:9]
[3:2]
[4:3]
[1:1]
[16:9]
[A Size(√2:1)]
[7:6]
9.5K : 9,520 x 4,080 6.2K : 6,240 x 2,672 4.8K : 4,768 x 2,040 UHD : 3,840 x 1,648 FHD : 1,920 x 824
9.5K : 9,520 x 6,328 6.2K : 6,240 x 4,144 4.8K : 4,768 x 3,168 UHD : 3,840 x 2,552 FHD : 1,920 x 1,280
9.5K : 8,432 x 6,328 6.2K : 5,520 x 4,144 4.8K : 4,224 x 3,168 UHD : 3,408 x 2,552 FHD : 1,696 x 1,280
9.5K : 6,328 x 6,328 6.2K : 4,144 x 4,144 4.8K : 3,168 x 3,168 UHD : 2,552 x 2,552 FHD : 1,280 x 1,280
9.5K : 9,520 x 5,352 6.2K : 6,240 x 3,512 4.8K : 4,768 x 2,680 UHD : 3,840 x 2,160 FHD : 1,920 x 1,080
9.5K : 8,944 x 6,328 6.2K : 5,856 x 4,144 4.8K : 4,480 x 3,168 UHD : 3,616 x 2,552 FHD : 1,808 x 1,280
9.5K : 7,856 x 6,328 6.2K : 5,152 x 4,144 4.8K : 3,920 x 3,168 UHD : 3,168 x 2,552 FHD : 1,584 x 1,280
* When a DC lens is attached, it can be used with a recording pixel count of 6.2K or less. |
||||||
| Color space | sRGB, Adobe RGB | ||||||
| Audio (intern) | Linear PCM (2 ch 48 kHz / 16 bit) | ||||||
| Recording pixels / Frame rate (Internal) | Camera Internal Record
|
||||||
| Continuous recording time (internal) | Up to 2 hours | ||||||
| Cinema DNG recording media limits (Internal) | SD Card (UHS-II) : UHD 8 bit 25 p or less, FHD 12 bit 59.94 p or less |
||||||
| Movie format (External) | 4:2:2 8 bit |
||||||
| Audio (external) | Linear PCM (2 ch 48 kHz/16 bit) | ||||||
| File size / Frame rate (External) | 4,096 x 2,160 (DCI 4K) / 24 p ※Only for RAW output |
||||||
| Auto format / Focus mode | Image plane phase-difference AF + Contrast detection system, Single AF, Continuous AF (with moving object prediction function), Manual Focus | ||||||
| AF Measurement DistanceDetecton Range / AF mode | -5 to 18 EV (F1.4:ISO 100) / Auto, 49-point selection mode, Free Move mode, Face/Eye Detection AF mode, Tracking AF mode | ||||||
| AF Lock | Half-press the shutter button, or press the AEL button (setting change required) | ||||||
| Metering System | Evaluative, Spot, Center Weighted Average | ||||||
| Metering Range | -5 to 18 EV (50 mm F1.4:ISO 100) | ||||||
| Still Image Shooting Mode | (P) Program AE (Program Shift capable), (S) Shutter Speed Priority AE, (A) Aperture Priority AE, (M) Manual | ||||||
| Movie Shooting Mode | (P) Program AE, (S) Shutter Angle Priority AE, (A) Aperture Priority AE, (M) Manual | ||||||
| Exposure Compensation | ±5 EV (in 1/3 stop increments) : ±3 EV at movie recording | ||||||
| AE Lock | Half-press the shutter button, or press the AEL button (setting change required) | ||||||
| Exposure Bracket | 3 shots / 5 shots stage exposure 3EV (1/3 Step, Standard→Underexposure→Overexposure) (Sequence changeable) | ||||||
| Image Stabilization System | Electronic system * Applicable only when shooting movies with MOV 59.94 p or less | ||||||
| White balance Settings | "12 types ( Auto, Auto[Lighting Source Priority], Daylight, Shade, Overcast, Incandescent, Fluorescent, Flash, Color Temperature[50K steps], Custom 1, Custom 2, Custom 3 )" | ||||||
| Shutter Type | Electronic shutter | ||||||
| Shutter Speed | 30 to 1/8,000 sec., Bulb up to 300 sec. | ||||||
| Drive Modes | Single Capture, Continuous, Self Timer (2sec. / 10sec.), Interval Timer | ||||||
| Monitor Type / Coverage | TFT color LCD, Aspect Ratio 3:2, 3.15 type, Approx. 2.1M dots , Electrostatic capacitance system touch panel / Approx. 100% | ||||||
| Light Emission Mode (External flash) | Red-eye Reduction / Slow Synchronization, Rear Curtain Synchronization | ||||||
| Flash Mode (External flash) | S-TTL automatic light control, Manual, Wireless flash, Multi-emission | ||||||
| Exposure control (External flash) | Max. ±3 EV in 1/3EV step increments | ||||||
| Flash Tuning Speed (External flash) | Max. 1/15 sec. * 1/10 sec. or less at 14 bit RAW | ||||||
| External Flash Support | Available when the HOT SHOE UNIT HU-11 (supplied with this product) is mounted. * S-TTL, Wireless support, X-sync. | ||||||
| Color mode | "15 types (Standard, Vivid, Neutral, Portrait, Landscape, Cinema, Teal and Orange, Sunset Red, Forest Green, Powder Blue, FOV Classic Blue, FOV Classic Yellow, Duotone, Monochrome, Off )" | ||||||
| Built-in Microphone / Speaker | Stereo microphone, Monaural speaker | ||||||
| Display Language | English / Japanese / German / French / Spanish / Italian / Simplified Chinese / Traditional Chinese / Korean / Russian / Dutch / Polish / Portuguese / Danish / Swedish / Norwegian / Finnish | ||||||
| USB | USB3.1 GEN1 Type-C (supports Mass Storage, Video Class(UVC), Camera Control) | ||||||
| HDMI | Type D（Ver.1.4） | ||||||
| External Microphone | Φ3.5 mm stereo mini jack (Plug-in power support) | ||||||
| Headphone output | Φ3.5 mm stereo mini jack (can be connected when using the dedicated ELECTRONIC VIEWFINDER EVF-11) | ||||||
| Flash-synchro Terminal | Dedicated terminal (with HOT SHOE UNIT HU-11 (supplied with this product) mounted) | ||||||
| Stof- en spatwaterdichte constructie | Yes | ||||||
| Power | Li-ion Battery Pack BP-51 *Internal battery charge via USB terminal available. *USB power supply available. | ||||||
| Still images | Approx. 240 images on fully charged battery | ||||||
| Movie | continuous recording | Approx. 60 min. on fully charged battery | ||||||
| Gewicht (gram) | 427 g (including battery and SD card), 375 g (Camera body only) | ||||||
| Operating Temperature | 0 - +40 °C | ||||||
| Operating Humidity | 85 % or less (non-condensing) | ||||||
| Accessoires | Li-ion Battery Pack BP-51, Strap, STRAP HOLDER SH-11, USB AC ADAPTER UAC-21, USB CABLE (C-C) SUC-41, HOT SHOE UNIT HU-11, Body Cap, Instruction Manual | ||||||
| Optional Accessories | HAND GRIP HG-11, LARGE HAND GRIP HG-21, LCD VIEWFINDER LVF-11, ELECTRONIC VIEWFINDER EVF-11, BASE PLATE BPL-11, CABLE RELEASE CR-41, BASE GRIP BG-11, DC CONNECTOR CN-21, BATTERY CHARGER BC-71, AC ADAPTER SAC-7P, STRAP HOLDER SH-11 (2pcs) | ||||||
| EAN-code | 085126939038 |
61 megapixels. The highest resolution presented by Sigma.
Leveraging our knowhow of image processing technology on Foveon sensors.
Thanks to the ultra-high resolution, Sigma fp L is able to unleash your imagination and feature a low-pass filter to make a further contribution to the optical performance.
The Sigma fp L features a Bayer sensor with approximately 61 effective megapixels, higher than any other Sigma camera before it. In addition to images with fine details, the fp L is capable of creating images that are high-definition and rich in color, thanks to its ultra-high pixel count and Sigma’s experience in developing cameras with a Foveon sensor, are renowned for both the exceptional resolving power and nuanced color gradients due to the unique nature of the X3 sensor. Furthermore, for its image quality that are in principle free of color artifacts, the Foveon sensor legacy was also behind the decision that the fp L should have a low-pass filter to reduce moiré to minimum levels. The use of a low-pass filter was a choice that made sense for a camera with an ample megapixels such as the Sigma fp L.
Higher resolution. Greater freedom.
Every shot is your dream shot.
Crop Zoom
A high pixel count means that images can stand extreme zooming or cropping. This was one aspect of an ultra-high pixel camera that led Sigma to give the fp L a cropped zoom feature that works in both the STILL and CINE modes. Thanks to its ample (approximately 61 effective) megapixels, the fp L can record in full HD quality even at its maximum 5x zoom; because this is accomplished simply by cropping with no digital enhancement, the image quality will not suffer. To use it in a more intuitive way, you can pinch to zoom on the LCD touch screen.
Never miss your moment.
Hybrid Autofocus
Contrast detection autofocus + Phase detection autofocus
In addition to high-precision contrast AF, the Sigma fp L features fast image area phase-detection AF. This hybrid AF allows users to enjoy smooth autofocus that is high-precision, fast, and excellent at tracking a moving subject, whether they are shooting stills or video.
Unlimited power supply.
Long hours of worry-free USB-C cable power supply
The Sigma fp L supports USB charging while the camera is on. You can shoot without interruption while charging the camera using a mobile battery, even outdoors or where you have no access to a power outlet. When using it as a webcam, just connect the fp L to a PC via USB and it works as an audio and video input device while getting its power supply from the PC. This means that you can use it for long hours without having to worry about the battery dying on you.
Carry all the amazing things in your pocket.
The world’s smallest and lightest full-frame mirrorless camera.*
With overall dimension of 112.6 x 69.9 x 45.3mm and body weight of 370g and 375g for the fp and the fp L, respectively, the Sigma fp family is the world’s smallest and lightest* full-frame mirrorless cameras. They are small enough to take for casual use, so you can enjoy the full-frame image quality for your everyday snaps.
*As of March 2021, by Sigma
Abundant of choices for every occasion.
L-Mount lenses.
The Sigma fp series uses the L-Mount*, characterized by a short flange focal length, large diameter, and superior durability. For interchangeable lenses, in addition to the wide-ranging choice of Sigma lenses, other manufacturers’ lenses can also be an option through the L-Mount Alliance with Leica Camera AG and Panasonic Corporation. With the Sigma MOUNT CONVERTER MC-21, Sigma SA mount and Sigma’s CANON EF mount lenses can be used, making the best out of one’s lens investment.
*The L-Mount Trademark is a registered Trademark of Leica Camera AG.
Make your communication more engaging than ever.
Transforming a Sigma fp to a webcam with just a USB cable.
By simply connecting it to a PC via USB, a Sigma fp camera can be used as a webcam. It will bring a stunning, full-frame image quality to live streaming and online communication including video conferencing.
Film like a professional
Supporting 12bit CinemaDNG recording
Supporting Blackmagic RAW and ProRes RAW HDMI outputs as standard
Professional video interface
For raw video data, the Sigma fp series supports 12-bit CinemaDNG external recording. With 4K UHD/24fps recording, it produces video data that can be used even in filmmaking. It also supports Blackmagic RAW and ProRes RAW over HDMI recording, so you can choose one according to your workflow.
For the operation system, the Sigma fp series features a dedicated interface that supports commonly used cinema cameras, which means it can be taken straight to video production settings.
Your tough companion. Wherever you go.
Dust and Splash Resistant Structure* / Large Heat Sink
A body covered with die-cast aluminum on the front and the back ensures superior robustness and heat dissipation while keeping the body weight light.
The Sigma fp series is protected with the dust and splash resistant sealing on a total of 42 points over the camera body. Combined with a large-size magnesium heat sink that prevents overheating, the Sigma fp series is a reliable choice for shooting in a wide range of conditions as well as long hours of use.
Sigma fp | Large Heat Sink (Multi-languages)
*Although this construction allows the lens to be used in light rain, it is not the same as being waterproof.
See outside the frames.
Diverse aspect ratios
In STILL mode, you have seven aspect ratios to choose from. You can either choose one that suits your mood and preference, or try out one that you don’t normally use to discover a new framing and style. The Sigma fp series’ diverse aspect ratio will bring you possibilities to experience something that may change the way you see things.
7 types of aspect ratios
Find your own expression
Cinemagraph / Fill Light / Color mode
In addition to a total of 15 color modes to choose from, the Sigma fp series features a number of functionalities such as Cinemagraph, which is animated GIF that is a hybrid between photography and video, and Fill Light, which is Sigma’s special light control function. These features specially created for the Sigma fp series will help you find your own style.
A camera that whispers. For enjoying precious moments
Full-time electronic shutter
Shutter shock, sound, and lags: these are disadvantages of mechanical shutters. The Sigma fp series is designed to minimize them in pursuit of a system to adapt to a variety of different shooting scenes. Shooting that requires precision where even the tiniest shake is to be eliminated; shooting in a sound-sensitive situation; shooting without ruining the ambience of the scene; and shooting with good response without missing the perfect shot. These types of shooting will open new horizons in video creation. Furthermore, the absence of a mechanical shutter makes the Sigma fp’s camera structure simpler, which in turn improves its reliability as a camera.
